Bessey Light-Duty Step-Over Bar Clamp

Now: $9.20 USD

Zoom

Estimated
$0.00 CAD

Clear All

LMU2.006	$9.20 USD
LMU2.00610+ Available$9.20 USD/ea

No Matching SKUs.

Details

The BESSEY LMU2.006 Light-Duty Step-Over Bar Clamp is designed for clamping around obstructions where a standard bar clamp can't reach. Its unique U-shaped fixed jaw allows the clamp to reach over lips, flanges, moldings, and other small protrusions, applying pressure exactly where it's needed.

Despite its lightweight construction, the LMU2.006 delivers up to 330 lbs. (1,470 N) of clamping force. Powder-coated zinc die-cast jaws, a hardened serrated steel rail, and a smooth ACME-threaded spindle provide dependable performance and long service life. Two non-marring plastic pressure caps help protect finished workpieces, making this clamp an excellent choice for woodworking, cabinet installation, hobby projects, and light-duty assembly.

Features:

Unique step-over U-shaped fixed jaw clamps around small obstructions
Delivers up to 330 lbs. (1,470 N) of clamping force
Lightweight powder-coated zinc die-cast jaws
Hardened serrated steel rail provides a secure, slip-resistant grip
Smooth ACME-threaded spindle for fast, effortless adjustment
Includes two non-marring plastic pressure caps to protect work surfaces
Compact and lightweight for easy handling
Ideal for woodworking, cabinetry, hobby projects, repairs, and light assembly

Specifications:

Model: LMU2.006
Product Type: Light-Duty Step-Over Bar Clamp
Clamping Capacity: 6" (152 mm)
Throat Depth: 2" (51 mm)
Maximum Clamping Force: 330 lbs. (1,470 N)
Rail Size: 19/32" × 7/32" (15 × 5.5 mm)
Jaw Material: Powder-Coated Zinc Die-Cast
Rail Material: Hardened Serrated Steel
Spindle: ACME-Threaded Steel
Pressure Pads: Two Non-Marring Plastic Caps
Jaw Style: Step-Over U-Shaped Fixed Jaw
Approximate Weight: 0.60 lbs. (0.27 kg)
Country of Origin: Germany
Applications: Clamping over moldings, flanges, lips, and other obstructions; woodworking, cabinetry, hobby projects, repairs, and light assembly
